Resin Model Moulding Pressure Tank 10Ltr

Regular price £240.55 Excluding VAT
Casting under pressure is the best way to make high quality resin castings. This is especially true with difficult recesses and complex moulds. Pressure casting compresses air bubbles to sizes hard to detected by the human eye creating a virtually bubble free casting. Simply cast your part in your mould and then insert your mould into the pressure pot. Apply positive air pressure from any regulated compressor and leave to cure under pressure.

These tanks are modified for casting only and can not be used for paint. All unused outlets are permanently capped with 150psi 316 stainless steel caps.

Internal Dimensions Height = 22cm Diameter = 26cm.

Important points regarding pressure tanks.

The maximum working pressure is governed by a mechanical safety valve, recommended good working practice is to use at a working pressure of 60 Psi or below.
Constant air supply - No pressure tank is 100% air tight so whilst in use it must be connected to an air supply so the unavoidable slight loss is automatically balanced.

Casting under pressure is the best way to make high quality resin castings. This is especially true with difficult recesses and complex moulds. Pressure casting compresses air bubbles to sizes hard to detected by the human eye creating a virtually bubble free casting. Simply cast your part in your mould and then insert your mould into the pressure pot. Apply positive air pressure from any regulated compressor and leave to cure under pressure.

These tanks are modified for casting only and can not be used for paint. All unused outlets are permanently capped with 150psi 316 stainless steel caps.

Internal Dimensions Height = 22cm Diameter = 26cm.

Important points regarding pressure tanks.

The maximum working pressure is governed by a mechanical safety valve, recommended good working practice is to use at a working pressure of 60 Psi or below.
Constant air supply - No pressure tank is 100% air tight so whilst in use it must be connected to an air supply so the unavoidable slight loss is automatically balanced.

All goods are supplied with a manufacturers twelve month warranty, (or longer in some cases), provided the goods are used in accordance with the manufacturer's instructions. This warranty does not apply to any defect which arises from general wear and tear, losses caused by loss of use of the goods, wilful or accidental damage, or negligence by you or any third party. The cost of returning goods for repair/replacement is the responsibility of the owner, we may request that the item is returned direct to the manufacturer for repair/replacement - if so we will liaise between both parties.

If the goods supplied to you are damaged on delivery they should be signed for as such and you should notify in writing via the e-mail address or fax number shown on the contact page within 48 hours. Your statutory rights are not affected.
