Anest Iwata

The Anest Iwata product range includes several spray guns, pumps and accessories that, based on their specifications, are useful during different painting phases and in different application fields, and that can consequently satisfy any need. The body shop, wood, leather and plastic, are just a few of the industrial sectors which can be supported by Anest Iwata products and our advice.
Shop By
Anest Iwata W400 Bellaria Classic Spray Gun Showcase Model
translation missing: en.products.product.regular_price £199.00
translation missing: en.products.product.regular_price £199.00
W400 Bellaria Showcase model with case and regulator
W400 Bellaria High TEC spray gun, complete with 600ml pot

A popular and reliable gravity feed spray gun with high transfer efficiency control and superior atomization.

    Less overspray means less wastage
    Fine atomisation spray pattern
    Improved LV2 air cap with two unique new air caps with Flat & Thin application technology.
    Only 250/270 l/min air consumption, giving the sprayer an excellent control of the fluid build.
    Stable, large and compact pattern shape.
    Perfect for HS Clear Coat.
    Easy to clean chrome body

1.3mm is ideal for automotive clear and direct gloss finishing, 1.4mm as 1.3mm with faster application.
Anest Iwata Lph80 Black Fury Mini Spray Gun
translation missing: en.products.product.regular_price £182.00 Sold Out
translation missing: en.products.product.regular_price £182.00 Sold Out

Anest Iwata LPH80 Black Fury 1.0mm - Limited edition model.

The LPH80 premium spot/smart repair spray gun offers a flat fan pattern distributes the fluid evenly meaning it’s never centre wet. This gives you an easy to blend application allowing smaller areas to be succesully repaired whilst still achieving excellent right first time colour match results.

The LPH80 HVLP center post gravity feed spray gun is ideal for large backgrounds, spot repair, blending, shading and touch-up. Spray patterns ranging from 1.6 inch round pattern to a full 5.5 inch fan pattern. Low operating air pressure and low 1.8 CFM allow the LPH80 to be run with small air compressor, perfect for mobile repair.

Ideal for small repairs (spot repairing)
Compact and lightweight (only 205 grams)
Fine atomization
Twilight chrom plated body
Suitable for solvent and water based paints
PTFE packing
70cc  gravity cup
Tested and approved by the major paint producers

Anest Iwata Az3 Hte-S Grey Bulldog Limited Edition Gravity Spray Gun
translation missing: en.products.product.regular_price £89.50
translation missing: en.products.product.regular_price £89.50

The limited edition Grey British Bulldog AZ3 by Anest Iwata - The latest addition to the AZ3 range of gravity spray guns from Anest Iwata, an evolution of the ever popular model.

This model is ideal for application of both base coats and and clear coats, for both water and solvent paint - one gun for all however best practice still recommends two guns.

The Chrome Flash has been specially designed by Anest Iwata engineers to offer an amazing application for the professional paint sprayer at a low price point.

Offer stocks include a free Airgunsa air regulator with gauge!!

  • New longer fan pattern, best method for the latest coatings
  • New high atomization air caps
  • All the internal parts are stainless - ideal for water borne and solvent based paints
  • Ergonomic gun design - New trigger and ergonomic grip shape to relieve stress on painting
  • Light weight & well balanced body - Gun head 20-50 g lighter than previous model
  • New air flow valve - Increased control precision
  • Improved AKULON cup - Improved paint cup with multi thread construction

A wide range of fluid tip sizes so there is an option to suit every coating.
Anest Iwata Dps 904 Wall Mounted Double Diaphragm Pump
translation missing: en.products.product.regular_price £795.00
translation missing: en.products.product.regular_price £795.00
Ideal for premium commercial transport, industrial finishing and fluid transfer.
Spray guns and hoses are also available if required - call us 0114 2706700 if help needed.

Pump Specs:

• Aluminium and alloy construction
• Simple and reliable operation
• 1.5 Bar / 23PSI minimum working pressure
• 6.8 Bar / 98PSI maximum working pressure
• 10 LPM maximum delivery
• 50cc per cycle
• Max 200 cycles per minute
• Weight 4Kg (Pump Only)
• CE certified
• Air pressure circuit conforms to safety standard PREN12621
• PR5 fluid regulator included to ensure smooth constant delivery

This ANEST-IWATA diaphragm paint pump complies to ATEX regulations 94/9/EC. Protection level: II 2 GX Suitable for use in Zones 1 and 2.

We have super reliable super smooth delivery double diaphragm pumps. Ideal for high volume painting demands such as furniture / retail solutions manufacturing, commercial transport and industrial finishing or where ever a large surface area needs coating to a high standard quick time. They are great for basic fluid transfers with a wide range of liquid products. All of our double diaphragm pumps are supplied ready to use complete with pressure gauge, air regulator, fluid delivery regulator, we can also supply complete with both air and fluid lines ranging from 5m to 20m and a choice of pressure fed spray guns.
Anest Iwata Dps 903 Cart Mounted Double Diaphragm Pump
translation missing: en.products.product.regular_price £895.00
translation missing: en.products.product.regular_price £895.00
Ideal for premium commercial transport, industrial finishing and fluid transfer.
Spray guns and hoses are also available if required - call us 0114 2706700 if help needed.

Pump Specs:

• Aluminium and alloy construction
• Simple and reliable operation
• 1.5 Bar / 23PSI minimum working pressure
• 6.8 Bar / 98PSI maximum working pressure
• 10 LPM maximum delivery
• 50cc per cycle
• Max 200 cycles per minute
• Weight 4Kg (Pump Only)
• CE certified
• Air pressure circuit conforms to safety standard PREN12621
• PR5 fluid regulator included to ensure smooth constant delivery

This ANEST-IWATA diaphragm paint pump complies to ATEX regulations 94/9/EC. Protection level: II 2 GX Suitable for use in Zones 1 and 2.

We have super reliable super smooth delivery double diaphragm pumps. Ideal for high volume painting demands such as furniture / retail solutions manufacturing, commercial transport and industrial finishing or where ever a large surface area needs coating to a high standard quick time. They are great for basic fluid transfers with a wide range of liquid products. All of our double diaphragm pumps are supplied ready to use complete with pressure gauge, air regulator, fluid delivery regulator, we can also supply complete with both air and fluid lines ranging from 5m to 20m and a choice of pressure fed spray guns.
Anest Iwata Ls400 Entech Hvlp Spray Gun Showcase Model
translation missing: en.products.product.regular_price £275.00
translation missing: en.products.product.regular_price £275.00
Iwata Supernova LS400 Entech HVLP Gravity Spraygun for basecoats only - 1.3mm ET is by far the most popular variant. ET tips are ideal for most basecoats, ETS tips are for heavier and more viscous basecoats offering larger droplets when atomising.

Performance: The Supernova delivers a consistent droplet size when atomising. This combined with the flat even Supernova pattern helps reduce common application issues. All Supernova gun are equipped with stainless steel fluid passages ideal for any type of material, solvent borne or waterborne.

Perfect Balance: The Supernova cup angle design guarantees perfect balance regardless of what cup size you choose.

Quick Release Air-Cap: The larger thread pattern of the air-cap make it both robust and easy to remove and is designed with low maintenance in mind. The new larger grip points on the outside of the air cap ring facilitate quick removal and refitting after cleaning.

Responsive Trigger: The responsive trigger action gives the painter stable air flow control during application. Accurate air pressure can now be set with either the air stroke or the fluid stroke.

Ergonomic Grip: An in-depth study by the University of Pavia into perfect balance and optimal ergonomics was closely considered by Pininfarina designers and Anest Iwata engineers to produce this state of the art spray gun. The slim ergonomic grip of the Supernova spray gun helps distribute weight and balance through the wrist, reducing the risk of repetitive strains.
Anest Iwata Ws400 Evo Spray Gun Showcase Model
translation missing: en.products.product.regular_price £275.00
translation missing: en.products.product.regular_price £275.00
Iwata Supernova WS400 Evo CLEAR Gravity Spraygun for clearcoats and direct gloss - 1.3mm HD is by far the most popular variant. HD tips are have a slightly higher flow rate and offer a wetter application.

Performance: The Supernova delivers a consistent droplet size when atomising. This combined with the flat even Supernova pattern helps reduce common application issues. All Supernova gun are equipped with stainless steel fluid passages ideal for any type of material, solvent borne or waterborne.

Perfect Balance: The Supernova cup angle design guarantees perfect balance regardless of what cup size you choose.

Quick Release Air-Cap: The larger thread pattern of the air-cap make it both robust and easy to remove and is designed with low maintenance in mind. The new larger grip points on the outside of the air cap ring facilitate quick removal and refitting after cleaning.

Responsive Trigger: The responsive trigger action gives the painter stable air flow control during application. Accurate air pressure can now be set with either the air stroke or the fluid stroke.

Ergonomic Grip: An in-depth study by the University of Pavia into perfect balance and optimal ergonomics was closely considered by Pininfarina designers and Anest Iwata engineers to produce this state of the art spray gun. The slim ergonomic grip of the Supernova spray gun helps distribute weight and balance through the wrist, reducing the risk of repetitive strains.
Anest Iwata Viuafg-N-Af-Mc Carbon Filter
translation missing: en.products.product.regular_price £49.53
translation missing: en.products.product.regular_price £49.53
The carbon filter element for the belt filter fitted to an Iwata 2010 airfed mask.

Replace this item as part of your routine maintenance schedule to ensure compliance with class 3 certification.

Note VIUAF2006 is now replaced by VIUAFG-N-AF-MC, VIUAFG-N-AF-MC is the current filter now both both old AF2010 and new AF2020 air fed mask models.

Filter only included, other images are for reference purposes only.
Anest Iwata Lph80 Red Fury Mini Spray Gun
translation missing: en.products.product.regular_price £182.00 Sold Out
translation missing: en.products.product.regular_price £182.00 Sold Out

Anest Iwata LPH80 Red Fury 1.0mm - Limited edition model.

The LPH80 premium spot/smart repair spray gun offers a flat fan pattern distributes the fluid evenly meaning it’s never centre wet. This gives you an easy to blend application allowing smaller areas to be succesully repaired whilst still achieving excellent right first time colour match results.

The LPH80 HVLP center post gravity feed spray gun is ideal for large backgrounds, spot repair, blending, shading and touch-up. Spray patterns ranging from 1.6 inch round pattern to a full 5.5 inch fan pattern. Low operating air pressure and low 1.8 CFM allow the LPH80 to be run with small air compressor, perfect for mobile repair.

Ideal for small repairs (spot repairing)
Compact and lightweight (only 205 grams)
Fine atomization
Twilight chrom plated body
Suitable for solvent and water based paints
PTFE packing
70cc  gravity cup
Tested and approved by the major paint producers

Anest Iwata Lph80 Hvlp Mini Spray Gun
£182.00
The LPH80 premium spot/smart repair spray gun offers a flat fan pattern distributes the fluid evenly meaning it’s never centre wet. This gives you an easy to blend application allowing smaller areas to be succesully repaired whilst still achieving excellent right first time colour match results.

The LPH80 HVLP center post gravity feed spray gun is ideal for large backgrounds, spot repair, blending, shading and touch-up. Spray patterns ranging from 1.6 inch round pattern to a full 5.5 inch fan pattern. Low operating air pressure and low 1.8 CFM allow the LPH80 to be run with small air compressor, perfect for mobile repair.

Ideal for small repairs (spot repairing)
Compact and lightweight (only 205 grams)
Fine atomization
Twilight chrom plated body
Suitable for solvent and water based paints
PTFE packing
70cc OR 250cc gravity cup
Tested and approved by the major paint producers

Anest Iwata Viuafg-N-Af-Mc Carbon Filter
translation missing: en.products.product.regular_price £49.53
translation missing: en.products.product.regular_price £49.53
A replacement carbon filter element for the belt filter fitted to an Iwata 2010 / 2020 airfed mask.

Replace this item as part of your routine maintenance schedule to ensure compliance with class 3 certification.

Note VIUAF2006 is now replaced by VIUAFG-N-AF-MC, VIUAFG-N-AF-MC is the current filter now both both old AF2010 and new AF2020 air fed mask models.

Filter only included, other images are for reference purposes only.
Anest Iwata Ws400 Evo Spraygun With Free Gauge
translation missing: en.products.product.regular_price £285.00
translation missing: en.products.product.regular_price £285.00
Iwata Supernova WS400 Evo CLEAR Gravity Spraygun for clearcoats and direct gloss - 1.3mm HD is by far the most popular variant. HD tips are have a slightly higher flow rate and offer a wetter application.

Performance: The Supernova delivers a consistent droplet size when atomising. This combined with the flat even Supernova pattern helps reduce common application issues. All Supernova gun are equipped with stainless steel fluid passages ideal for any type of material, solvent borne or waterborne.

Perfect Balance: The Supernova cup angle design guarantees perfect balance regardless of what cup size you choose.

Quick Release Air-Cap: The larger thread pattern of the air-cap make it both robust and easy to remove and is designed with low maintenance in mind. The new larger grip points on the outside of the air cap ring facilitate quick removal and refitting after cleaning.

Responsive Trigger: The responsive trigger action gives the painter stable air flow control during application. Accurate air pressure can now be set with either the air stroke or the fluid stroke.

Ergonomic Grip: An in-depth study by the University of Pavia into perfect balance and optimal ergonomics was closely considered by Pininfarina designers and Anest Iwata engineers to produce this state of the art spray gun. The slim ergonomic grip of the Supernova spray gun helps distribute weight and balance through the wrist, reducing the risk of repetitive strains.
