The SATAjet X 5500 Clear Coat Edition shines with its newly developed, special nozzle set for clear coat application. The optimised material distribution in combination with a finer atomisation allows users to achieve closed wetting even at a low layer thickness.

Exclusive now! Limited design with a red body and black control elements!

Advantages at a glance:

• Special clear coat nozzle based on proven I-nozzle technology
• Fine, homogeneous atomisation for a perfect clear coat
• Closed wetting even at low layer thickness
• I-nozzle jet geometry allows controlled application
• The special clear coat nozzle bears the additional designation “cc” (SATAjet X 5500 RP 1.3cc)

The basic dispenser system consists of six tubes for the safe storage of cups, lids and sieves relating to two different cup sizes. With just three extra tubes contained in the SATA RPS Extension Kit (195776), a third cup size can be added.

Due to the new dispenser system, everything has its defined place. Either next to each on the wall or, compactly arranged, on rotating spindles available as accessories. These spindles can be optionally mounted to the wall (SATA RPS Rotawall Adapter Kit, 196543), a workbench or directly on to the floor (SATA RPS Rotafloor Adapter Kit, 196550 + 197723).

Benefits

With only 3 components only (cup, lid and sieve), the system is easy and safe to handle. The cups attach directly on all modern SATA sprayguns without an adapter, keeping the system extremely light and easy to handle. The sprayguns remain easy to clean, as there are no undercuts in their material passages where paint residues could settle.

The ventilation valve in the bottom of the cup ensures constant flow, thus providing an even material delivery during the entire painting process up to the very last droplet. This allows efficient paint application achieving perfect finishes.

Standard version:

• 2x Cup Tubes
• 2x Lid Tubes
• 2x Sieve Tubes
• 2x Aluminium Slats

Due to the high cleaning efficiency, colour changes require only extremely short cleaning interruptions. This optimises the painter’s work processes and the capacity utilisation of the spray booth, thus increasing the bodyshop profitability.

• Rapid and safe colour change when using disposable cups, such as SATA RPS – even with critical changes, e.g. black/white
• Thorough cleaning of both material passages and air cap
• Saves time and increases productivity and profitability
• Suitable for waterborne and solvent-based paint systems
• Storage area for prepared RPS disposable cups
• To connect large cleaning agent containers
• Recommended for wall-mounting inside the mixing room, as there is no need for spray air supply
• Optional: Hose for extracting solvent vapours

Technical Specifications

• Inlet pressure: max. ca. 6 – 8 bar (87 – 116 psi)
• Dimensions: 310 x 485 x 222 mm
• Net Weight: 10.0 kg

With the aim to eliminate incorrect inlet pressure as a possible cause for quality problems, SATA currently offer sprayguns with digital pressure gauges integrated in the gun handle, while for non-digital SATA sprayguns there is the retrofit option of the SATA Adam 2 available. The advantages of both solutions are obvious: they are compact, lightweight and precise, and enable the painter to keep the pressure always under control.

With the SATA Adam 2 U, consisting of a SATA Adam 2 U Dock and the known SATA Adam 2 display, the painter has now the option to adjust and monitor the inlet pressure in digital form on any make of spray gun.

The display indicates the inlet pressure with an accuracy of +/- 0.05 bar, while the adjustment screw on the side allows to set the pressure precisely. This new addition to the SATA Adam 2 series offers tangible advantages in terms of cost and flexibility. Basically, the painter needs only invest in a single SATA Adam 2 digital display unit which can be utilised with all his SATA or non-SATA sprayguns that have been fitted with the appropriate SATA Adam 2 Dock or SATA Adam 2 U dock.

Display available here.

To ensure a fast drying process following waterborne paint, it is vital to apply as much air as possible within a short period of time onto the painted object. To achieve this, the SATA dry jet 2 also relies on the Venturi principle like its predecessor: In addition to the compressed air feeding the system, a multiple of ambient air is drawn in that serves directly to accelerate the drying process.

The design of the flat fan nozzle gives the dry jet 2 an extra large air footprint, further increasing the drying efficiency, helping reduce the flash-off time and enhancing the quality of the drying process simultaneously.

• The recommended Inlet Pressure is 29 to 35 psi and uses CFM 8.2 to 9.35 CFM
• The Venturi principle design the CFM is magnified x10 to give a 92.35 CFM output

– Due to the integrated air regulation, the painter can precisely adjust the air supply to adapt the airflow volume to ideally suit the requirements of the painted object

• A painter can dry entire side of a car with one SATA dry jet 2

An integrated 125μ sieve serves to filter contamination from the aspirated air. The SATA dry jet 2 uses the same 125μ filter as the SATA RPS cup lids, the filters are also available separately in a 10 pack (part no. 222125)

Ergonomically optimised SATA 100 BF spray gun body in state-of-the-art design with small dimensions and low weight for fatigue-free working nozzles sizes ranging from 1.2 to 2.1 for primer and filler work 100% hand checked nozzle sets ensure the constant high SATA quality – for complete guns as well as spare nozzle sets.

• Smoothly polished gun surface for easy and quick cleaning including material passages.
• Now with material-flow control with counter nut and enhanced thread, as with the topcoat spray guns
• Air micrometre with graduations to adjust atomisation air
• Suitable for waterborne paints – paint needle and nozzle are made of stainless steel and the spray gun body has been carefully anodized
• Self-adjusting air and material packings with a long lifetime significantly reduce the need for servicing
• Comfortable trigger with low trigger-pull resistance and integrated paint needle cover, minimising cleaning effort and increasing the lifetime of the needle packing
• CCS-Clip (Colour Code System) to mark each spray gun individually
• Single-handed round/flat control to adjust the spray pattern to the object which is to be painted
• QCC quick cup connector for quick cup changes and fast cleaning as well as for the use of the RPS disposable cup system without the need for an additional adaptor
